DC solar · JIABO Practical Series
JBY DC Solar Swimming Pool Pumps
Solar-powered circulation pumps designed for swimming pools and other low-head filtration loops.
Power200-2,200 W
Maximum flow6-36 m³/h
Maximum head9-18 m
Outlet32/38-50 mm
Applications
Where this family fits.
- Swimming pools
- Off-grid filtration
- Water circulation
Construction
Catalog-specified materials.
- Plastic outlet, pump head and impeller
- Aluminium body
- 1 m cable
- 8 m maximum suction
Representative selection
Example models.
Values shown are catalog maximums, not a guaranteed operating point. Use the performance curve and system calculation for final selection.
| Model | Power | Max flow | Max head | Outlet |
|---|---|---|---|---|
| JBY6-9-24-200 | 200 W | 6 m³/h | 9 m | 32/38 mm |
| JBY14-13-72-600 | 600 W | 14 m³/h | 13 m | 50 mm |
| JBY25-14-192-1500 | 1,500 W | 25 m³/h | 14 m | 50 mm |
| JBY36-18-280-2200 | 2,200 W | 36 m³/h | 18 m | 50 mm |
Avoid undersizing
Let us match the pump to your system.
Include flow, total dynamic head, well diameter, water level, pipe length, location and power source.
