Request a quoteDC solar · JIABO Practical Series
This narrow solar borehole-pump family combines a 3-inch-diameter format with stainless-steel impellers for deep-well irrigation, tank filling and remote-community water supply. Compare the exact duty curve, water chemistry and bore clearance before selection.
Applications
Construction
Representative selection
Values shown are catalog maximums, not a guaranteed operating point. Use the performance curve and system calculation for final selection.
| Model | Power | Max flow | Max head | Outlet |
|---|---|---|---|---|
| JBYD4.0-30-24-300 ↗ | 300 W | 4.0 m³/h | 30 m | 1.25" |
| JBYD4.5-75-72-600 ↗ | 600 W | 4.5 m³/h | 75 m | 1.25" |
| JBYD4.5-130-192-1500 ↗ | 1,500 W | 4.5 m³/h | 130 m | 1.25" |
| JBYD4.5-200-280-2200 ↗ | 2,200 W | 4.5 m³/h | 200 m | 1.25" |
Buyer questions
A stainless-steel impeller may be preferred for durability or water-service requirements, but the exact stainless grade, water chemistry and other wetted materials still need confirmation for the selected model.
No. Maximum head is a curve endpoint. Calculate total dynamic head from pumping water level, elevation, required outlet pressure and pipe losses, then check the flow available at that head.
Avoid undersizing
Include flow, total dynamic head, well diameter, water level, pipe length, location and power source.
